Mimaki JFX200-2513 Printhead - M022625
Mimaki JFX200-2513 Printhead - M022625
Couldn't load pickup availability
In stock to ship same day, this brand new Mimaki GEN5 Printhead - OEM (M022625) is compatible with Mimaki JFX200 Series.
Mimaki GEN5 Printhead - OEM (M022625)
Compatible with Mimaki JFX200 Series
Description
Original Mimaki GEN5 printhead M022625. Designed for JFX200-2513 printers. Supports 2-4 color configurations with 8-level grayscale for high-precision output and consistent drop control.
Key Specs
- Nozzles: 4 x 320 (1,280 total)
- Resolution: Up to 600 npi
- Drop size: 7-35 pl (native 7 pl)
- Jetting frequency: Up to 60 kHz
- Drop velocity: 7 m/s
- Nozzle spacing: 0.1693 mm
Construction & Performance
- Piezo: D33 stacked PZT
- Materials: SST, nickel alloy, epoxy
- Coated stainless steel nozzle plate
- Integrated heater & thermistor
- Operating temp: Up to 80?C
- Rated life: 100B actuations per nozzle
Dimensions
89 x 25 x 69 mm (excluding cables)
Compatibility
- Mimaki JFX200-2513
Note
Firmware update may be required:
- JFX200-2513: v2.60+
- JFX200-2531: v2.50+
Need a compatibility check?
For high-value printheads and printer parts, email mikea@globalgarage.net with your printer model, current part number, and any photos of the existing component. Global Garage can help confirm fit before purchase.
Buying assurance from Global Garage
- Ships from Colorado when inventory is available.
- Compatibility help is available before you order.
- High-value printhead orders are reviewed for part-number fit.
- Contact Global Garage if you need confirmation for your printer model.
